20176B-02000 Forklift Truck Support Hydraulic Cylinder
The 20176B-02000 is a purpose-specified support hydraulic cylinder used in forklift truck chassis applications where a compact, high-load support function is required. With a 50mm bore, 45mm rod, and 125mm stroke, this cylinder occupies a very small axial envelope while delivering meaningful force output at rated working pressure. The 364mm installation distance (pin-to-pin in the retracted position) determines the chassis mounting geometry. Support cylinders in this category are used in outrigger stabilizers, counterweight lift mechanisms, and chassis leveling systems where the cylinder must hold a static load for extended periods between actuation cycles.
Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Model | 20176B-02000 | OEM reference number |
| Cylinder Diameter | 50 mm | Bore ID |
| Rod Diameter | 45 mm | Hard chrome plated |
| Stroke | 125 mm | Full extension travel |
| Installation Distance | 364 mm | Pin-to-pin retracted |
| Application | Forklift truck support / stabilizer | Chassis-mounted support function |
| Load Characteristic | Static load hold dominant | Low cycle count, long hold duration |
Support Cylinder Design Priorities
A support cylinder differs from a positioning cylinder in one critical operational respect: the load it supports is often static for extended periods — minutes to hours — rather than being cycled rapidly. This places the primary performance demand on internal bypass leakage rather than cycle endurance. Any bypass past the piston seal allows the supported component to settle gradually, potentially causing misalignment in a leveling application or contact in a stabilizer application where the support cylinder holds the forklift chassis off the ground.
Performance Highlights
High-quality piston seal minimises internal bypass during extended static load-hold periods.
45mm rod in a 50mm bore provides exceptional rod stability and maximises annulus-side force for retraction.
Manufactured to 20176B-02000 dimensional specification for direct OEM replacement.
Seal kits available for in-field service without complete cylinder replacement.
To request pricing for the 20176B-02000 support cylinder, custom specifications, or an OEM supply assessment, contact Hangzhou Ever-Power Hydraulic Cylinder Co., Ltd. at +86-571-88220653 or [email protected]. Our address is Shenhua Road, Hangzhou. Use the contact form for a response within one business day.
